Nano

SKU: NC10U

Portable Nano PCs: flexible storage in the palm of your hand.

Our runrate products are barebone but we also configure specs based on your specific requirements:

The NC10U series is a palm-sized, 4K capable and low-power PC with the new Intel Whiskey Lake-U processor. A selection of Intel 8th generation ULV processors not only provides higher performance but also affords minimal power consumption. Room for up to 32 GB of DDR4 RAM allows you to increase system performance easily. Built-in HDMI 2.0a and DisplayPort outputs added the ability to drive dual 4K UHD displays. Despite its tiny body of 0.8 liters, the NC10U series still packs excellent connectivity – USB 3.2 Gen1, USB 2.0, RS232, M.2, SATA 6Gbps, Giga LAN and WiFi module. Besides, one 2.5″ drive as well as one M.2 SSD card can be installed. Perfect for a variety of uses in Home/Work PC, HTPC, and Digital Signage.

The NC10U series is powered by the 8th Generation Intel® Celeron® ULV processor (Whiskey Lake-U) and with built-in memory controller as well as integrated UHD graphics to provide better system efficiency and graphics performance.

*Core i3/ i5 / i7 processor options available.

Despite its tiny body, the NC10U series allows easy installation of up to 1x 15mm (7/9.5/12.5/15mm) 2.5” HDD/SSD to provide a more flexible storage capacity without volume restriction.

The NC10U series is designed for easy configuration. Users can simply open both upper and lower covers to easily install memory module, HDD, and other components.

The NC10U series includes HDMI and DisplayPort to support dual-screen displays to increase productivity and efficiency.

The NC10U series features HDMI 2.0a to support 4K (4096 x 2160) resolution at 60FPS as well as the transmission of HDR video, allowing for vivid streaming and more accurate color.

With native M.2 2280/2260/2242 Type M slot, the NC10U series offers considerably faster storage performance and expansion capacity for M.2 SSD and Wi-Fi modules.

*M.2 supports both SATA and PCIe storage interfaces.

In addition to HDMI and DisplayPort, the NC10U series provides multiple I/O options including RS232, USB 2.0, USB 3.2, and SD Card Reader. One built-in USB 3.2 Type-C offers users with more convenience with no up or down orientation required for plugs.

The NC10U series has excellent network connectivity powered by Intel® i211 Gigabit LAN and supports fast speed WiFi IEEE 802.11 b/g/n with wireless module built-in.

Shuttle’s heat-pipe cooling system with smart fan design allows for constant air circulation between the inside and outside of the machine, which guarantees high stability and low noise during long term operation.

The NC10U series uses industrial capacitors to meet the environmental operation demands of commercial applications.

*With the use of SSD and Wide Range Temp. SODIMM.

The NC10U series is VESA mount compatible and capable of mounting to the rear of a monitor or a TV, which fits seamlessly into any office, home or commercial environment.

Save energy costs as well as the cost of on-site service with Power-On by RTC function. Set automatic ‘Power On’ and ‘Power Off’ times by RTC via BIOS. Power on by RTC can also be turned on and off with the Windows task scheduler.

Watchdog Timer provides excellent security protection for systems that need to operate continuously for a long period of time. Use Shuttle’s Watch Dog utility to maintain normal operation and stability of the system at all times.

  • – Windows 10 64bit
  • – Linux
