Heavy-duty arms provide strong support for larger and heavier TVs up to 120kg,it basically holds all types of TVs from 43”-90”. TV installation and removal are made easy through a unique quick-release mechanism. Toolless tilting delivers optimal viewing angles. Integrated cable management creates a clean appearance.
Features:
- ● Cable Management: keeps everything organized
- ● Extending Arm: provides a wide range of viewing angles
- ● Swiveling Arm(s): offer(s) maximum viewing flexibility (makes every seat the best seat)
- ● Free-Tilting Design: makes easy forward or backward adjustment for better viewing and reduced glare
- ● Quick-Release Latch: locks/unlocks the display in place
Specifications
| Product Category: Full-motion TV Wall Mount |
| Rank: Standard |
| Material: Steel |
| Metal Sheet Thickness: Bracket Arm THK=1.5mm cold-rolled sheet,VESA Panel THK=2mm cold-rolled sheet,Wall Plate THK=3mm pickling sheet(Bracket Arm THK=0.059" cold-rolled sheet,VESA Panel THK=0.079" cold-rolled sheet,Wall Plate THK=0.12" pickling sheet) |
| Pipe Size: 50x25x1.5mm Square Steel Tube(2"x0.98"x0.059" Square Steel Tube) |
| Surface Finish: Powder Coating: |
| Color: Fine Texture Black |
| Dimensions: 703x710x430mm(27.7"x28"x16.9") |
| Fit Screen Size: 43"-90" |
| Fit Curved TV: Yes |
| Mounting Hole Pattern: VESA Only |
| VESA Compatible: 200x200,300x200,400x200,300x300,400x300,400x400,600x400 |
| Max. Mounting Hole: 610x410 |
| Weight Capacity: 120kg(264lbs) |
| Strength Tested: 4 Times Approved |
| Profile: 75~703mm(3"~27.7") |
| Swivel Range: +60°~-60° |
| Screen Level: +5°~-15° |
| Screen Freely Tilting: Yes |
| Installation: Solid Wall,Double Stud(406mm/450mm/600mm) Panel Type: Detachable Panel |
| Wall Plate Type: Fixed Wall Plate |
| Direction Indicator: Yes |
| Cable Management: Yes |
| Bubble Level: Hook-on Bubble Level(Included in Components Package) |
| Accessory Kit Package: Compartment Polybag |
| Instruction Manual Included: Yes |
| Instruction Manual Included: Yes |
| Samsung Screw Kit: No |
| By Function: Full-motion |
Package Information
| Package: Type: Gift Box |
| Unit Packing Size: 83x33.7x7.5CM |
| Volume: 0.02 |
| Unit GW/NW: 15.84KG/14.940KG |
| Carton Size: 84.5x35.5x9.5CM |
| Q'ty/Carton: 1 |
| GW/NW: 17KG/15KG |
| Q'ty/20'GP: 947 |
| Q'ty/40'GP: 1964 |
| Q'ty/40'HP: 2245 |
