Easy to use and install, the popular model LP22-46F is designed to fit any 37”-70” Flat Panel TV up to 45kgs/99lbs. It features preset height and leveling adjustments that allow TV to be perfectly positioned after hanging. Strength has been tested for a minimum of four times its stated load capacity. The locking bar provides anti-theft function which will require a padlock. It also has side decorative caps for an elegant look. Compatible with VESA hole up to 600×400.
Features:
- ● Leveling adjustments: allow TV to be perfectly positioned after hanging
- ●Integrated Bubble Level: assures alignment
- ● Anti-Theft Locking Bar: for additional security preventing any unwanted removal (extra padlock required)
- ● Decorative Covers: for a more elegant look
Specifications
| Product Category: Tilt TV Wall Mount |
| Rank: Standard |
| Material: Steel,Plastic |
| Metal Sheet Thickness: Bracket Arm THK=1.5mm cold-rolled sheet,Wall Plate THK=2mm cold-rolled sheet(Bracket Arm THK=0.059" cold-rolled sheet,Wall Plate THK=0.079" cold-rolled sheet) |
| Surface Finish: Powder Coating |
| Color: Fine Texture Black |
| Dimensions: 26x715x440mm(1"x28.1"x17.3") |
| Fit Screen Size: 37"-70" |
| Fit Curved TV: Yes |
| Mounting Hole Pattern: VESA & Universal |
| VESA Compatible: 200x200,400x200,300x300,400x400,600x400 |
| Max. Mounting Hole: 600x400 |
| Weight Capacity: 45kg(99lbs) |
| Strength Tested: 4 Times Approved |
| Profile: 26mm(1") |
| Screen Level: ±8mm |
| Installation: Solid Wall,Double Stud(406mm/450mm/600mm) |
| Panel Type: Detachable Panel |
| Wall Plate Type: Fixed Wall Plate |
| Cable Management: No |
| Anti-theft: Yes |
| Bubble Level: BBuilt-in Bubble Level (Integrated on Wall Plate/VESA Panel) |
| Accessory Kit Package: Normal/Ziplock Polybag,Compartment Polybag |
| Instruction Manual Included: Yes |
| Samsung Screw Kit: No |
| By Function: Fixed |
Package Information
| Package: Type: Gift Box |
| Unit Packing Size: 73.5x16.5x4CM |
| Volume: 0.00 |
| Unit GW/NW: 3.03KG/2.790KG |
| Carton Size: 75x26.5x18CM |
| Q'ty/Carton: 6 |
| GW/NW: 20KG/17KG |
| Q'ty/20'GP: 4524 |
| Q'ty/40'GP: 9384 |
| Q'ty/40'HP: 10722 |
